1000B-5002FX
RoHS
/
Package SMD/SMT
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1:1 -1.2dB Surface Mount
PDF
/
Buying Options
Total Price: USD $50.82
Unit Price: USD $50.823672
≥1 USD $50.823672
≥200 USD $20.279053
≥500 USD $19.601597
≥1000 USD $19.266808
Inventory: 4902
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 17.53mm
Height Seated (Max) 0.235 5.97mm
Technical
Turns Ratio - Primary:Secondary 1:1
Transformer Type LAN 10/100/1000 Base-T
Lead/Base Style Gull Wing
Inductance 350μH
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.690Lx0.480W 17.53mmx12.19mm
Published 2017
Packaging Bulk
Physical
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
Alternative Model
