PA2008NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
Pulse Transformer 2:1:1 1500Vrms 1.15Ohm Prim. DCR 0.575Ohm Sec. DCR 8Term. SMD
PDF
/
Inventory: 3639
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 9.02mm
Height Seated (Max) 0.300 7.62mm
Technical
Pulse Rise Time-Max 55.5ns
ET (Volt-Time) 52VμS
Turns Ratio - Primary:Secondary 2.1:1
Transformer Type PULSE TRANSFORMER
Isolation Voltage 1500V
Application GATE DRIVE
DC Resistance (DCR) 1.15Ohm
Inductance 1.43mH
Depth 8.64mm
Number of Functions 3
Additional Feature BREADTH DIM INCLUDES TERMINAL ALSO
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.355Lx0.340W 9.02mmx8.64mm
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~130°C
Physical
Number of Pins 8
Mounting Type Surface Mount
Mount Surface Mount
