PA1836NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
PULSE XFMR 4.5UH
PDF
/
Buying Options
Total Price: USD $6
Unit Price: USD $6.0016
≥1 USD $6.0016
≥10 USD $4.55928
≥100 USD $4.439424
≥500 USD $4.07968
Inventory: 119
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 21.84mm
Length 29.21mm
Height Seated (Max) 0.450 11.43mm
Technical
Number of Primary Winding 3
Number of Secondary Winding 1
Turns Ratio - Primary:Secondary 2:2.33
Transformer Type SMPS TRANSFORMER
Operating Frequency-Max 200kHz
Input Voltage (Max) 36V
Input Voltage (Min) 9V
Output Voltage 1 5V
Inductance 4.5μH
Physical Dimension L29.21XB21.84XH11.43 (mm)
Power Rating 95W
Additional Feature LENGTH & HEIGHT DIMENSION INCLUDES TERMINAL ALSO
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.860Lx1.150W 21.84mmx29.21mm
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
