PA1576NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
Switching Transformer 6:3:1 26V to 68V 3.3V 0.036Ohm/0.058Ohm Prim. DCR 0.0035Ohm Sec. DCR Surface Mount
PDF
/
Buying Options
Total Price: USD $4.67
Unit Price: USD $4.669985
≥1 USD $4.669985
≥150 USD $1.863005
≥450 USD $1.801299
≥1050 USD $1.771102
Inventory: 8971
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 0.551Lx0.516W 14.00mmx13.11mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature BREADTH DIM INCLUDES TERMINAL ALSO, FORWARD TRANSFORMER
Physical Dimension L14.0XB17.65XH12.07 (mm)
Inductance 230.4μH
Max Output Voltage 3.3V
Max Input Voltage 68V
Operating Frequency-Max 300kHz
Transformer Type SMPS TRANSFORMER
Number of Secondary Winding 1
Number of Primary Winding 2
Dimensions
Height Seated (Max) 0.485 12.32mm
Length 14mm
Width 17.65mm
Compliance
RoHS Status RoHS Compliant
