TX9027
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1:2/1:2 1500Vrms Surface Mount
PDF
/
Inventory: 3890
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 16.26mm
Length 28.57mm
Height Seated (Max) 0.285 7.24mm
Technical
Turns Ratio - Primary:Secondary 1:2 Transmitter, 1:2 Receiver
Transformer Type T1/E1 (Quad)
Inductance 1.2mH
Operating Temperature (Min) -40°C
Physical Dimension 28.57mm X 16.26mm X 7.24mm
Operating Temperature (Max) 85°C
Packing Method TUBE
Additional Feature COMPATIBLE WITH PMC-SIERRAS PM 4318 OCTLIU; TURNS RATIO: 1:2; 1:2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 1.125Lx0.485W 28.58mmx12.32mm
Published 2007
Packaging Bulk
Physical
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
