TX3025NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1CT:1CT/1:1 16Term. Gull Wing SMD
PDF
/
Inventory: 2154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Number of Pins 16
Weight 0.04oz 1.14g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
Size / Dimension 0.505Lx0.280W 12.83mmx7.11mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Depth 9.53mm
Physical Dimension L12.83XB7.11XH6.22 (mm)
Inductance 100μH
Lead/Base Style Gull Wing
Transformer Type T3/E3 (Dual)
Turns Ratio - Primary:Secondary 1:1
Dimensions
Height Seated (Max) 0.245 6.22mm
Length 12.83mm
Width 7.11mm
Compliance
RoHS Status RoHS Compliant
Alternative Model
