TX1473NL
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Transformers / Pulse Transformers
Description
32 T1/E1 (Octal) Surface Mount Tube Pulse Transformer 1.5kV 1.2mH 10.8mm -40C~85C
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 1380
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Number of Pins 32
Weight 0.1oz 2.85g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2009
Size / Dimension 1.000Lx0.310W 25.40mmx7.87mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Depth 10.8mm
Physical Dimension L25.4XB10.8XH7.11 (mm)
Inductance 1.2mH
Lead/Base Style Gull Wing
Isolation Voltage 1.5kV
Transformer Type T1/E1 (Octal)
Turns Ratio - Primary:Secondary 1:2
Dimensions
Height 7.11mm
Height Seated (Max) 0.295 7.49mm
Length 25.4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
