TX1314NLT
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
TRANSFORMER 1:1/1.26 1.2MH SMD
PDF
/
Inventory: 8786
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7.62mm
Height Seated (Max) 0.250 6.35mm
Technical
Turns Ratio - Primary:Secondary 1:1
Transformer Type T1/E1 (Single)
Lead/Base Style Gull Wing
DC Resistance (DCR) 800mOhm
Inductance 1.2mH
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Size / Dimension 0.300Lx0.276W 7.62mmx7.00mm
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 0.02oz 0.57g
Number of Pins 6
Mounting Type Surface Mount
Mount Surface Mount
