T4031T
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
1 DATACOM TRANSFORMER Surface Mount TRAY Pulse Transformer 14Ohm 1.5kV 13000μH 1.65CS:1CT
PDF
/
Inventory: 9614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Number of Pins 10
Technical
Published 2003
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 25°C
Min Operating Temperature 0°C
Packing Method TRAY
Number of Functions 1
Depth 17.65mm
Physical Dimension L13.46XB13.11XH12.07 (mm)
DC Resistance (DCR) 14Ohm
Lead/Base Style Gull Wing
Application ISDN
Isolation Voltage 1.5kV
Transformer Type DATACOM TRANSFORMER
Return Loss 20 dB
Primary Inductance 13000 μH
Turns Ratio (NpNs) 1.65CS:1CT
Dimensions
Height 13.46mm
Length 17.65mm
Width 13.11mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
