T1096NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
XFRMR 1CT:1.41CT/1CT:1.41CT SMD
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.82435
≥1 USD $2.82435
≥10 USD $2.318
≥100 USD $2.24485
≥500 USD $2.17265
≥1000 USD $2.10045
Inventory: 30004
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.11mm
Length 12.83mm
Height Seated (Max) 0.245 6.22mm
Height 6.22mm
Technical
Return Loss 11 dB
Turns Ratio - Primary:Secondary 1:1.41
Transformer Type T1/E1 (Dual)
Isolation Voltage 1.5kV
Lead/Base Style Gull Wing
Inductance 1mH, 1mH
Physical Dimension L12.83XB7.11XH6.22 (mm)
Approval Agency UL
Reach Compliance Code unknown
Depth 9.53mm
Additional Feature HEIGHT DIM INCLUDES TERMINAL ALSO, TURNS RATIO: 1CT:1.41CT; 1CT:1.41CT
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.505Lx0.280W 12.83mmx7.11mm
Published 2008
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 16
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
Alternative Model
