T1006NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1:2CT 0.6Ohm Prim. DCR 1Ohm Sec. DCR 32Term. Gull Wing SMD
PDF
/
Inventory: 1413
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Number of Pins 32
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2006
Size / Dimension 1.000Lx0.310W 25.40mmx7.87mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Additional Feature STANDARD: UL, BREADTH DIMENSION INCLUDES TERMINAL ALSO
Packing Method TAPE & REEL
Depth 10.8mm
Physical Dimension L25.4XB10.8XH7.11 (mm)
Inductance 1.2mH
DC Resistance (DCR) 600mOhm
Lead/Base Style Gull Wing
Transformer Type T3/E3 (Quad)
Turns Ratio - Primary:Secondary 1:2
Dimensions
Height Seated (Max) 0.295 7.49mm
Length 25.4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
