PE-68841NLT image
Favorite
PE-68841NLT image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Pulse Transformers
Description Audio Transformers / Signal Transformers SMD T1/CEPT/ISDN-Pri 1200uH 1.7Ohm 2-Port
PDF
/
Inventory: 7447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 11.58mm
Length 17.15mm
Height Seated (Max) 0.340 8.64mm
Height 8.64mm

Technical

Return Loss 11 dB
Turns Ratio - Primary:Secondary 1:2
Transformer Type T1/E1 (Dual)
Isolation Voltage 1.5kV
Lead/Base Style Gull Wing
Inductance 1.2mH, 1.2mH
Physical Dimension L17.15XB11.58XH8.64 (mm)
Approval Agency UL
Depth 15.24mm
Additional Feature HEIGHT DIM INCLUDES TERMINAL ALSO, TURNS RATIO: 1CT:2CT; 1CT:2CT
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.675Lx0.456W 17.15mmx11.58mm
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Weight 0.09oz 2.56g
Number of Pins 12
Mounting Type Surface Mount
Mount Surface Mount
