PE-68828NLT image
Favorite
PE-68828NLT image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Pulse Transformers
Description Audio Transformers / Signal Transformers SMD T1/CEPT/ISDN-Pri 1200uH 1Ohm 2-Port
PDF
/
Inventory: 1526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Number of Pins 12
Weight 0.09oz 2.56g

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2008
Size / Dimension 0.675Lx0.456W 17.15mmx11.58mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
ECCN Code EAR99
Additional Feature HEIGHT DIM INCLUDES TERMINAL ALSO, TURNS RATIO: 1CT:1CT; 1CT:1CT
Depth 15.24mm
Approval Agency UL
Physical Dimension L17.15XB11.58XH8.69 (mm)
Inductance 1.2mH, 1.2mH
Lead/Base Style Gull Wing
Isolation Voltage 1.5kV
Transformer Type T1/E1 (Dual)
Turns Ratio - Primary:Secondary 1:1
Return Loss 11 dB

Dimensions

Height 8.64mm
Height Seated (Max) 0.340 8.64mm
Length 17.15mm
Width 11.58mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
