PE-68515LT image
Favorite
PE-68515LT image
Favorite
RoHS
/
Package Module
Category Transformers / Pulse Transformers
Description Telecom Transformer 1:1 16Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 17005
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.370 9.40mm
Height 9.91mm

Technical

Return Loss -12 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type LAN 10/100 Base-T
Isolation Voltage 1.5kV
Insertion Loss (dB) -1 dB
Lead/Base Style Gull Wing
Depth 12.95mm
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Size / Dimension 1.000Lx0.350W 25.40mmx8.89mm
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C

Physical

Weight 3.500004g
Number of Pins 16
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
