PE-68056NLT
RoHS
/
Package Module
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1:1 16Term. Gull Wing SMD
PDF
/
Inventory: 6479
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Number of Pins 16
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Published 2007
Size / Dimension 0.920Lx0.385W 23.37mmx9.78mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature BREADTH AND HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Number of Functions 1
Depth 12.7mm
Physical Dimension L23.37XB12.7XH5.84 (mm)
Lead/Base Style Gull Wing
Application 10 BASE-T
Insertion Loss (dB) -1 dB
Isolation Voltage 1500V
Transformer Type LAN 10G Base-T
Turns Ratio - Primary:Secondary 1:1
Return Loss -18 dB
Turns Ratio (NpNs) 1:1
Dimensions
Height Seated (Max) 0.230 5.84mm
Length 23.37mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
