PE-64943NL
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1CT:2CT 0.7Ohm Prim. DCR 1.2Ohm Sec. DCR 6Term. PC Pin Thru-Hole
PDF
/
Buying Options
Total Price: USD $7.03
Unit Price: USD $7.026641
≥1 USD $7.026641
≥180 USD $2.804354
≥480 USD $2.711139
≥1020 USD $2.663874
Inventory: 3453
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DIP
Number of Pins 6
Weight 0.07oz 1.99g
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2008
Size / Dimension 0.500Lx0.350W 12.70mmx8.89mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
ECCN Code EAR99
Depth 8.89mm
Approval Agency UL
Inductance 1.2mH
DC Resistance (DCR) 700mOhm
Lead/Base Style PC Pin
Isolation Voltage 1.5kV
Transformer Type T1/E1 (Single)
Turns Ratio - Primary:Secondary 1:2
Return Loss 11 dB
Dimensions
Height 6.35mm
Height Seated (Max) 0.250 6.35mm
Length 12.7mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
