PE-5760NL
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Transformers / Pulse Transformers
Description
Pulse Transformers THT General Purpose 5000uH 3.9Ohms
PDF
/
Buying Options
Total Price: USD $5.73
Unit Price: USD $5.7288
≥1 USD $5.7288
≥10 USD $4.35688
≥100 USD $4.242304
≥500 USD $3.89825
Inventory: 82
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 8.89mm
Height Seated (Max) 0.250 6.35mm
Height 6.35mm
Technical
ET (Volt-Time) 25VμS
Turns Ratio - Primary:Secondary 1:1.1
Transformer Type DATACOM TRANSFORMER
Isolation Voltage 500V
Application GENERAL PURPOSE
Lead/Base Style PC Pin
DC Resistance (DCR) 3.9Ohm
Inductance 5mH
Depth 12.7mm
Number of Functions 1
Power Rating 500mW
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.500Lx0.350W 12.70mmx8.89mm
Published 2007
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 0.048oz 1.37g
Number of Pins 6
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
