HX6098FNLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
MDL,SIN,1GPP,1:1,SM,T&R
PDF
/
Buying Options
Total Price: USD $6.48
Unit Price: USD $6.4768
≥1 USD $6.4768
≥10 USD $5.03536
≥100 USD $4.899488
≥500 USD $4.218896
≥1000 USD $4.028376
Inventory: 524
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2014
Size / Dimension 0.715Lx0.595W 18.16mmx15.11mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO
Number of Functions 4
Physical Dimension L18.16XB15.11XH6.6 (mm)
Inductance 120μH
Application GENERAL PURPOSE
Isolation Voltage 1500V
Transformer Type LAN 10/100/1000 Base-T
Turns Ratio - Primary:Secondary 1CT:1CT Transmitter, 1CT:1CT Receiver
Turns Ratio (NpNs) 1:1
Dimensions
Height Seated (Max) 0.260 6.60mm
Length 18.16mm
Width 15.11mm
Compliance
RoHS Status RoHS Compliant
