HX2326NLT
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Transformers / Pulse Transformers
Description
MODULE 10/100B-T POE SMD
PDF
/
Buying Options
Total Price: USD $4.21
Unit Price: USD $4.2064
≥1 USD $4.2064
≥10 USD $3.40472
≥100 USD $2.752992
≥500 USD $2.57928
≥1000 USD $2.463296
≥3000 USD $2.390854
Inventory: 1073
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Weight 0.04oz 1.14g
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2013
Size / Dimension 0.500Lx0.280W 12.70mmx7.11mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Number of Functions 1
Physical Dimension L12.70XB7.11XH5.97 (mm)
Application 10/100 BASE-TX; ETHERNET
Isolation Voltage 1500V
Transformer Type Isolation and Data Interface (Encapsulated)
Turns Ratio - Primary:Secondary 1CT:1CT
Turns Ratio (NpNs) 1:1; 1:1
Dimensions
Height Seated (Max) 0.245 6.22mm
Length 12.7mm
Width 7.11mm
Compliance
RoHS Status RoHS Compliant
