HX2305NLT image
Favorite
HX2305NLT image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Pulse Transformers
Description Telecom Transformer 1:1 24Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $8.97
Unit Price: USD $8.9672
≥1 USD $8.9672
≥10 USD $6.86664
≥100 USD $5.817504
≥500 USD $5.722112
≥1000 USD $5.436024
Inventory: 788
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 15.11mm
Length 13.61mm
Height Seated (Max) 0.251 6.37mm

Technical

Return Loss -10 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type Isolation and Data Interface (Encapsulated)
Isolation Voltage 1500V
Insertion Loss (dB) -1.4 dB
Application 10/100 BASE-TX; ETHERNET
Lead/Base Style Gull Wing
Physical Dimension L13.61XB15.11XH6.12 (mm)
Depth 18.67mm
Number of Functions 2
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.518Lx0.595W 13.16mmx15.11mm
Series Star Magnetics?
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Weight 0.1oz 2.85g
Number of Pins 24
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
