H5008FNL
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Transformers / Pulse Transformers
Description
PULSE XFMR 1CT:1CT TX 1CT:1CT RX
PDF
/
Buying Options
Total Price: USD $7.88
Unit Price: USD $7.8848
≥1 USD $7.8848
≥10 USD $6.30784
Inventory: 1130
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 13.67mm
Length 18.44mm
Height Seated (Max) 0.231 5.87mm
Height 5.87mm
Technical
Return Loss -16 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type LAN 10/100/1000 Base-T, Power over Ethernet (PoE)
Isolation Voltage 1.5kV
Insertion Loss (dB) -1.2 dB
Application GENERAL PURPOSE
Lead/Base Style Gull Wing
DC Resistance (DCR) 650mOhm
Inductance 350μH
Physical Dimension L18.44XB13.67XH5.87 (mm)
Approval Agency UL
Depth 18.87mm
Number of Functions 4
Subcategory Other Transformers
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.743Lx0.538W 18.87mmx13.67mm
Published 2013
Packaging Bulk
Operating Temperature 0°C~70°C
Physical
Core Material Plastic
Number of Pins 24
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
