H2260NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1: 1 0.65Ohm Prim. DCR 0.65Ohm Sec. DCR 16Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $4.56
Unit Price: USD $4.5584
≥1 USD $4.5584
≥10 USD $3.6916
≥100 USD $2.79598
≥500 USD $2.67036
≥1000 USD $2.591785
≥3000 USD $2.513245
Inventory: 513
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.11mm
Length 12.7mm
Height Seated (Max) 0.240 6.10mm
Height 6mm
Technical
Turns Ratio (NpNs) 1:1
Primary Inductance 350 μH
Return Loss -10 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type Isolation and Data Interface (Encapsulated)
Isolation Voltage 1.5kV
Insertion Loss (dB) -1.1 dB
Application 10/100 BASE-TX; ETHERNET
Lead/Base Style Gull Wing
Physical Dimension L12.7XB7.11XH6.0 (mm)
Depth 9.65mm
Number of Functions 1
Shielding Unshielded
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.500Lx0.280W 12.70mmx7.11mm
Series Star Magnetics?
Published 2007
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 0.1oz 2.85g
Number of Pins 16
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
Alternative Model
