H1062NL image
Favorite
H1062NL image
Favorite
RoHS
RoHS RoHS compliant
Package Module
Category Transformers / Pulse Transformers
Description MODULE XFRMR QUAD ETHR LAN40SOIC
PDF
/
Buying Options
Total Price: USD $10.89
Unit Price: USD $10.887
≥1 USD $10.887
≥10 USD $8.93285
≥100 USD $8.65355
≥500 USD $8.37425
≥1000 USD $8.09495
Inventory: 7307
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Number of Pins 40
Weight 0.14oz 3.99g

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Published 2016
Size / Dimension 1.125Lx0.480W 28.58mmx12.19mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Termination SMD/SMT
ECCN Code EAR99
Connector Type TELECOM AND DATACOM CONNECTOR
Shielding Unshielded
Depth 16mm
Lead/Base Style Gull Wing
Insertion Loss (dB) -0.5 dB
Isolation Voltage 1.5kV
Transformer Type Isolation and Data Interface (Encapsulated)
Turns Ratio - Primary:Secondary 1:1
Return Loss -21 dB

Dimensions

Height 5.84mm
Height Seated (Max) 0.230 5.84mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
