H1060NL
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1:1 40Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 20008
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Number of Pins 40
Weight 0.14oz 3.99g
Technical
Operating Temperature 0°C~70°C
Packaging Bulk
Published 2009
Size / Dimension 1.125Lx0.480W 28.58mmx12.19mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
ECCN Code EAR99
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Packing Method TUBE
Number of Functions 4
Depth 16mm
Physical Dimension L28.58XB12.19XH5.84 (mm)
Lead/Base Style Gull Wing
Application 10/100 BASE-TX
Insertion Loss (dB) -0.5 dB
Transformer Type LAN
Turns Ratio - Primary:Secondary 1:1
Return Loss -12 dB
Dimensions
Height Seated (Max) 0.230 5.84mm
Length 28.58mm
Width 12.19mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
