H1019NLT
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Transformers / Pulse Transformers
Description
Telecom Transformer 1:1 16Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $38.95
Unit Price: USD $38.95
≥1 USD $38.95
≥10 USD $31.95895
≥100 USD $30.9605
≥500 USD $29.9611
≥1000 USD $28.96265
Inventory: 3628
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 9.91mm
Length 25.4mm
Height Seated (Max) 0.245 6.22mm
Technical
Turns Ratio (NpNs) 1CT:1CT; 1CT:1CT
Primary Inductance 350 μH
Return Loss -14 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type Isolation and Data Interface (Encapsulated)
Isolation Voltage 1500V
Insertion Loss (dB) -1 dB
Application 10/100 BASE-T
Lead/Base Style Gull Wing
Physical Dimension 25.4mm X 9.91mm X 5.97mm
Depth 12.83mm
Number of Functions 1
Additional Feature COMPATIBLE WITH BROADCOM; INTEL; ICS; TDK; MIRCEL & NATIONAL SEMICONDUCTOR
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 1.000Lx0.390W 25.40mmx9.91mm
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 16
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
