EX2001QNLT
RoHS
/
Package Module
Category Transformers / Pulse Transformers
Description
MODULE 10BASE-T INTRFACE 1:1 SMD
PDF
/
Buying Options
Total Price: USD $6.86
Unit Price: USD $6.8552
≥1 USD $6.8552
≥10 USD $5.62495
≥100 USD $5.4492
≥500 USD $5.27345
≥1000 USD $5.0977
Inventory: 1658
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Number of Pins 16
Weight 0.09oz 2.56g
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2005
Size / Dimension 0.930Lx0.390W 23.62mmx9.91mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Functions 1
Depth 12.95mm
Reach Compliance Code unknown
Physical Dimension L23.62XB12.95XH5.84 (mm)
Lead/Base Style Gull Wing
Application 10 BASE-T
Insertion Loss (dB) -1 dB
Isolation Voltage 1800V
Transformer Type Isolation and Data Interface (Encapsulated)
Turns Ratio - Primary:Secondary 1:1
Dimensions
Height Seated (Max) 0.230 5.84mm
Length 23.62mm
Compliance
RoHS Status RoHS Compliant
