RoHS
/
Package /
Category Transformers / Pulse Transformers
Description Telecom Transformer 1:1.9 1500Vrms 0.65Ohm Prim. DCR 0.37Ohm Sec. DCR Surface Mount
PDF
/
Inventory: 6291
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 12.07mm
Length 15.24mm
Height 11.43mm

Technical

Turns Ratio - Primary:Secondary 1:1.9
Transformer Type TELECOM TRANSFORMER
Isolation Voltage 1.5kV
Lead/Base Style Gull Wing
DC Resistance (DCR) 650mOhm
Operating Temperature (Min) -40°C
Physical Dimension 15.24mm X 12.07mm X 11.43mm
Operating Temperature (Max) 85°C
Packing Method TRAY
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete

Physical

Mount Surface Mount
