B4023NL image
Favorite
B4023NL image
Favorite
RoHS
RoHS RoHS compliant
Package DIP
Category Transformers / Pulse Transformers
Description Telecom Transformer 1:1CT 6Term. PC Pin Thru-Hole
PDF
/
Inventory: 7487
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 8.89mm
Height Seated (Max) 0.250 6.35mm

Technical

Return Loss 13 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type VDSL
Insertion Loss (dB) 0.75 dB
Lead/Base Style PC Pin
Depth 12.7mm
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.500Lx0.350W 12.70mmx8.89mm
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Weight 0.04oz 1.14g
Number of Pins 6
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
