B2134T
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
IC CHIP
PDF
/
Inventory: 9175
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
Additional Feature LENGTH DIM INCLUDES TERMINAL ALSO
Subcategory Other Transformers
Power Rating 12W
Packing Method TAPE & REEL
Reach Compliance Code compliant
Operating Temperature (Max) 125°C
Physical Dimension L29.21XB21.84XH11.18 (mm)
Operating Temperature (Min) -40°C
Output Voltage 1 12V
Input Voltage (Min) 36V
Input Voltage (Max) 57V
Application SIGNAL
Operating Frequency-Max 200kHz
Isolation Voltage 1800V
Transformer Type SMPS TRANSFORMER
Output Voltage 2 3.3V
Number of Secondary Winding 2
Number of Primary Winding 2
Primary Inductance 195 μH
Turns Ratio (NpNs) 32/4
Output Current 1 3.5A
Load Resistance 0.012Ohm
Output Current 2 0.1A
Dimensions
Height 11.18mm
Length 29.21mm
Width 21.84mm
Compliance
RoHS Status Non-RoHS Compliant
