B1074B image
Favorite
B1074B image
Favorite
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description Telecom Transformer 1:5.4 4.2Ohm Prim. DCR 0.35Ohm Sec. DCR 10Term. Gull Wing SMD
PDF
/
Inventory: 5987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 13.11mm
Length 17.65mm
Height 13.46mm

Technical

Return Loss 15 dB
Turns Ratio - Primary:Secondary 1:5.4
Transformer Type TELECOM TRANSFORMER
Isolation Voltage 1.5kV
Lead/Base Style Gull Wing
DC Resistance (DCR) 4.2Ohm
Physical Dimension L13.46XB13.11XH12.32 (mm)
Depth 17.65mm
Shielding Unshielded
Packing Method TRAY
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2004

Physical

Number of Pins 10
Mount Surface Mount
