DA103MC-R
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Transformers / Pulse Transformers
Description
Audio Transformers / Signal Transformers 1:1 turn 4-5.96mH SM 0.91uH 2000Vrms 6Pin
PDF
/
Buying Options
Total Price: USD $1.64
Unit Price: USD $1.64122
≥1 USD $1.64122
≥10 USD $1.54832
≥100 USD $1.46068
≥500 USD $1.378
≥1000 USD $1.3
≥3000 USD $1.22642
Inventory: 9797
Minimum: 1
-
+
Technical Details
Dimensions
Height 6.35mm
Height Seated (Max) 0.250 6.35mm
Length 9.52mm
Width 9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Technical
ET (Volt-Time) 28VμS
Turns Ratio - Primary:Secondary 1:1
Transformer Type BROADCAST AUDIO TRANSFORMER
Lead/Base Style Gull Wing
Inductance 7.75mH
Approval Agency UL
Packing Method TAPE & REEL
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.354Lx0.375W 9.00mmx9.52mm
Series DA100
Packaging Bulk
Operating Temperature 0°C~70°C
Physical
Number of Pins 6
Package / Case DIP
Mounting Type Surface Mount
Mount Surface Mount
