DA101MC
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Transformers / Pulse Transformers
Description
MURATA POWER SOLUTIONS DA101MC DIGITAL AUDIO DATA TRANSMISSION TRANSFOR
PDF
/
Buying Options
Total Price: USD $1.64
Unit Price: USD $1.64122
≥1 USD $1.64122
≥10 USD $1.54832
≥100 USD $1.46068
≥500 USD $1.378
≥1000 USD $1.3
≥3000 USD $1.22642
Inventory: 1261
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DIP
Number of Pins 6
Weight 930mg
Technical
Operating Temperature 0°C~70°C
Series DA100
Size / Dimension 0.354Lx0.375W 9.00mmx9.52mm
JESD-609 Code e3
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Packing Method TUBE
Shielding Unshielded
Depth 12.7mm
Frequency 50Hz
Approval Agency UL
Inductance 2.06mH
Lead/Base Style Gull Wing
Isolation Voltage 2kV
Transformer Type BROADCAST AUDIO TRANSFORMER
Turns Ratio - Primary:Secondary 1:1
Return Loss 46.8 dB
ET (Volt-Time) 15VμS
Dimensions
Height 6.35mm
Height Seated (Max) 0.250 6.35mm
Length 9.52mm
Width 9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
