78602/1C image
Favorite
78602/1C image
Favorite
RoHS
RoHS RoHS compliant
Package DIP
Category Transformers / Pulse Transformers
Description MURATA POWER SOLUTIONS 78602/1C Pulse Transformer, PCB, 1:1:1, 2 mH, 0.66 ohm, 20 Vs, 1 kV, 786 Series
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3816
≥1 USD $1.3816
≥10 USD $1.364
≥100 USD $1.3464
≥500 USD $1.32
≥1000 USD $1.2496
≥3000 USD $1.1616
Inventory: 1205
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case DIP
Number of Pins 6
Weight 1.1g

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Series 786
Size / Dimension 0.375Lx0.354W 9.52mmx9.00mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Capacitance 72pF
Number of Functions 1
Depth 9mm
Number of Outputs 2
Approval Agency UL
Inductance 2mH
DC Resistance (DCR) 660mOhm
Lead/Base Style PC Pin
Isolation Voltage 1kV
Transformer Type General Purpose
Turns Ratio - Primary:Secondary 1:1.1
ET (Volt-Time) 20VμS

Dimensions

Height 6.35mm
Height Seated (Max) 0.250 6.35mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
