TX02-4400PI
RoHS
/
Package PDIP
Category Transformers / Pulse Transformers
Description
IC INTERFACE TRANSFORMER 8-DIP
PDF
/
Inventory: 3349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 35 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case PDIP
Number of Pins 8
Weight 0.07oz 1.99g
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2005
Series TX02-4400
Size / Dimension 0.378Lx0.255W 9.59mmx6.48mm
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Pure Tin (Sn)
Additional Feature HEIGHT DIMENSION INCLUDES TERMINALS ALSO
Number of Functions 1
Depth 10.92mm
Approval Agency UL
Lead/Base Style PC Pin
Application GENERAL PURPOSE
Number of Drivers 2
Transformer Type Isolation and Data Interface (Encapsulated)
Turns Ratio - Primary:Secondary 3:1
Primary Inductance 0.97 μH
Turns Ratio (NpNs) 3:1
Dimensions
Height Seated (Max) 0.180 4.57mm
Length 10.16mm
Compliance
RoHS Status RoHS Compliant
