B78476A8135A003
RoHS
/
Package /
Category Transformers / Pulse Transformers
Description
1 DATACOM TRANSFORMER Surface Mount HEIGHT DIMENSION INCLUDES TERMINAL ALSO Pulse Transformer 350muH -10dB 18.7mm -1dB
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.1976
≥1 USD $4.1976
≥10 USD $3.40208
≥100 USD $2.750528
≥500 USD $2.57664
≥1000 USD $2.46092
Inventory: 1215
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 13.8mm
Height 5.72mm
Technical
Primary Inductance 350 μH
Return Loss -10 dB
Turns Ratio - Primary:Secondary 1:1
Transformer Type DATACOM TRANSFORMER
Insertion Loss (dB) -1 dB
Application 1000 BASE-T; LAN
Lead/Base Style Gull Wing
Physical Dimension L15.2XB13.8XH5.72 (mm)
Approval Agency UL
Depth 18.7mm
Number of Functions 1
Packing Method TAPE & REEL
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Pbfree Code yes
Packaging Tape and Reel
Physical
Number of Pins 24
Mount Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
