VPH5-0053TR-R image
Favorite
VPH5-0053TR-R image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Transformers / Pulse Transformers
Description INDUCTOR/TRANSFORMER 7.63UH SMD
PDF
/
Buying Options
Total Price: USD $18
Unit Price: USD $18.001172
≥1 USD $18.001172
≥230 USD $7.182876
≥460 USD $6.942615
≥1035 USD $6.824454
Inventory: 4354
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 12
Weight 18.597287g
Core Material Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series VERSA-PAC?
Size / Dimension 0.827Lx1.122W 21.00mmx28.50mm
Tolerance 20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 28.5mm
Military Standard Not
Inductance 7.63μH
DC Resistance (DCR) 71.1mOhm
Current 1.41A
Max DC Current 3.07A
Transformer Type General Purpose
Inductance - Parallel 10.1 μH
Inductance - Series 363.6 μH
Number of Coils 6
ET (Volt-Time) 98.4VμS

Dimensions

Height 10.795mm
Height Seated (Max) 0.425 10.80mm
Length 21mm
Width 28.4988mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
