B59960C0080A051
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
Radial Disc Through Hole UR VDE Ceramic Ceramic PTC Resettable Fuse 80V 130mA 5.6Ohms -40C~85C
PDF
/
Inventory: 7057
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial, Disc
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2014
Size / Dimension 0.433Dia x 0.138 T 11.00mmx3.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Type Ceramic
Approval Agency UR, VDE
Lead Spacing 0.197 5.00mm
Current - Max 4.3A
Current - Hold (Ih) (Max) 130mA
Voltage - Max 80V
Current - Trip (It) 265mA
Resistance @ 25°C 5.6Ohms
Dimensions
Height Seated (Max) 0.571 14.50mm
Compliance
RoHS Status ROHS3 Compliant
