PFRA.300
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
Resettable Fuses - PPTC PTC 30V I hold 3.0
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.46552
≥100 USD $0.4378
Inventory: 1000
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Disc
Terminal Shape WIRE
Weight 660.005248mg
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series PFRA
Size / Dimension 0.472Lx0.118W 12.00mmx3.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Polymeric
Resistance 80mOhm
Voltage - Rated 30V
HTS Code 8533.40.80.70
Current Rating 40A
Approval Agency cURus, TUV
Lead Pitch 5.8mm
Lead Spacing 0.201 5.10mm
Lead Diameter 810 μm
Max Current Rating 40A
Power Dissipation 2W
Max Voltage Rating (DC) 30V
Rated (AC) Voltage (URac) 40V
Hold Current 3A
Current - Hold (Ih) (Max) 3A
Thermistor Application TEMPERATURE SENSING
Time to Trip 10.8s
Resistance - Initial (Ri) (Min) 20mOhm
Resistance - Post Trip (R1) (Max) 80mOhm
Trip Current 6A
Dimensions
Diameter 12mm
Height 18.3mm
Height Seated (Max) 0.720 18.30mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
