PTGL07BD150N3B51A0
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 15OHM DISC
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.903275
≥1 USD $0.903275
≥200 USD $0.361048
≥500 USD $0.349231
≥1500 USD $0.342667
Inventory: 6332
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.528 13.40mm
Technical
Resistance @ 25°C 15Ohm
Current - Trip (It) 195mA
Voltage - Max 32V
Thermistor Application OVERLOAD PROTECTION
Current - Hold (Ih) (Max) 100mA
Current - Max 1.5A
Lead Spacing 0.197 5.00mm
Subcategory Non-linear Resistors
HTS Code 8533.40.80.70
Terminal Finish Tin/Copper (Sn/Cu)
Type Ceramic
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance 30%
Size / Dimension 0.291Dia x 0.157 T 7.40mmx4.00mm
Series POSISTOR?, PTGL
Packaging Bulk
Operating Temperature -10°C~60°C
Physical
Number of Pins 2
Terminal Shape WIRE
Package / Case Radial, Disc
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
