PTGL07AR4R6H2B51A0
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
MURATA PTGL07AR4R6H2B51A0POSISTOR, PTC, CIRCUIT PROTECTION
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.205417
≥1 USD $0.205417
≥200 USD $0.079496
≥500 USD $0.076699
≥1500 USD $0.075321
Inventory: 6189
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Disc
Terminal Shape WIRE
Number of Pins 2
Technical
Operating Temperature -10°C~60°C
Packaging Bulk
Series POSISTOR?, PTGL
Size / Dimension 0.291Dia x 0.157 T 7.40mmx4.00mm
Tolerance 25%
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Ceramic
Resistance 4.6Ohm
Terminal Finish Tin/Copper (Sn/Cu)
HTS Code 8533.40.80.70
Operating Supply Voltage 30V
Lead Spacing 0.197 5.00mm
Max Supply Voltage 30V
Max Current Rating 2A
Current - Hold (Ih) (Max) 340mA
Thermistor Application OVERLOAD PROTECTION
Current - Trip (It) 610mA
Trip Current 700mA
Resistance @ 25°C 4.6Ohm
Dimensions
Height Seated (Max) 0.528 13.40mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
