PTGL07AR250H4B51A0
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
Thermistor PTC 25 Ohm 25% 2-Pin Radial Ammo Pack
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.623628
≥1 USD $0.623628
≥200 USD $0.249451
≥500 USD $0.240261
≥1500 USD $0.236322
Inventory: 4095
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 4.5mm
Height Seated (Max) 0.528 13.40mm
Height 4.5mm
Technical
Resistance @ 25°C 25Ohm
Trip Current 260mA
Thermistor Application OVERLOAD PROTECTION
Hold Current 140mA
Current - Max 1A
Max Current Rating 1A
Voltage 80V
Lead Spacing 0.197 5.00mm
Operating Supply Voltage 80V
Lead Pitch 5mm
Current Rating 1mA
Depth 4.5mm
Power Rating 1.3W
HTS Code 8533.40.80.70
Terminal Finish Tin/Copper (Sn/Cu)
Resistance 25Ohm
Type Ceramic
ECCN Code EAR99
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance 25%
Size / Dimension 0.291Dia x 0.177 T 7.40mmx4.50mm
Series POSISTOR?, PTGL
Packaging Tape & Box (TB)
Operating Temperature -10°C~60°C
Physical
Number of Pins 2
Terminal Shape WIRE
Package / Case Radial, Disc
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
