RXEF090-2
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
LITTELFUSE RXEF090-2 RESETTABLE FUSE, PTC, 72V, 900mA, RADIAL
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.43648
≥100 USD $0.4224
≥500 USD $0.355168
≥1000 USD $0.294888
≥3000 USD $0.268118
Inventory: 1165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Disc
Surface Mount NO
Terminal Shape WIRE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2010
Series PolySwitch?, RXEF
Size / Dimension 0.441Dia x 0.118 T 11.20mmx3.00mm
JESD-609 Code e3
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Type Polymeric
Terminal Finish Tin (Sn)
Additional Feature 0.2-0.31 OHMS AT 20 DEG CEL
Packing Method TR
Reach Compliance Code unknown
Approval Agency CQC, CSA, TUV, UL
Lead Spacing 0.199 5.05mm
Current - Max 40A
Rated (AC) Voltage (URac) 72V
Hold Current 900mA
Thermistor Application TEMPERATURE SENSING
Voltage - Max 72V
Time to Trip 7.2s
Resistance - Initial (Ri) (Min) 200mOhm
Resistance - Post Trip (R1) (Max) 470mOhm
Current - Trip (It) 1.8A
Trip Current 1.8A
Dimensions
Height Seated (Max) 0.622 15.80mm
Compliance
RoHS Status ROHS3 Compliant
