RGEF900-2
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 16V 9A RADIAL
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.748
≥1 USD $0.748
≥10 USD $0.72512
≥100 USD $0.67848
≥500 USD $0.56144
≥1000 USD $0.467808
≥3000 USD $0.456122
Inventory: 1107
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.854 21.70mm
Technical
Current - Trip (It) 15.3A
Resistance - Post Trip (R1) (Max) 13.5mOhm
Resistance - Initial (Ri) (Min) 4.7mOhm
Time to Trip 5.5s
Voltage - Max 16V
Thermistor Application TEMPERATURE SENSING
Current - Hold (Ih) (Max) 9A
Rated (AC) Voltage (URac) 16V
Current - Max 100A
Lead Spacing 0.199 5.05mm
Approval Agency CSA, TUV, UL
Rated Power Dissipation (P) 3.3W
Packing Method TR, 14.6 INCH
Additional Feature RESISTANCE RANGE(MIN-MAX): 0.0047-0.0091
Type Polymeric
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 0.532Lx0.100W 13.50mmx2.50mm
Series PolySwitch?, RGEF
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Terminal Shape WIRE
Surface Mount NO
Package / Case Radial, Disc
Mounting Type Through Hole
Supply Chain
Factory Lead Time 10 Weeks
