AGRF500-2
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 16V 5A RADIAL
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.7216
≥1 USD $0.7216
≥10 USD $0.70224
≥100 USD $0.65736
≥500 USD $0.544016
≥1000 USD $0.453288
≥3000 USD $0.441971
Inventory: 1127
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.614 15.60mm
Technical
Trip Current 9.4A
Current - Trip (It) 9.4A
Resistance - Post Trip (R1) (Max) 34mOhm
Resistance - Initial (Ri) (Min) 14mOhm
Time to Trip 2.5s
Voltage - Max 16V
Thermistor Application TEMPERATURE SENSING
Hold Current 5A
Rated (AC) Voltage (URac) 16V
Current - Max 100A
Lead Spacing 0.199 5.05mm
Rated Power Dissipation (P) 2.7W
Reach Compliance Code unknown
Packing Method TR
Additional Feature RESISTANCE RANGE(MIN-MAX): 0.014-0.024
Type Polymeric
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Discontinued
Pbfree Code yes
Size / Dimension 0.409Dia x 0.122 T 10.40mmx3.10mm
Series PolySwitch?, AGRF
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Terminal Shape WIRE
Surface Mount NO
Package / Case Radial, Disc
Mounting Type Through Hole
Supply Chain
Factory Lead Time 10 Weeks
