PTS18128V200
RoHS
RoHS compliant
RoHS compliantPackage 1812 (4532 Metric), Concave
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESETTABLE SMD 1812 8V 2.0A
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.1936
≥100 USD $0.1848
≥500 USD $0.164736
≥1000 USD $0.153384
≥3000 USD $0.13633
Inventory: 1164
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1812 (4532 Metric), Concave
Weight 453.59237mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2011
Series PolyTron?, PTS1812
Size / Dimension 0.179Lx0.128W 4.55mmx3.24mm
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
Termination SMD/SMT
Type Polymeric
Resistance 60mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated DC 8V
Case Code (Metric) 4532
Approval Agency cURus, TUV
Case Code (Imperial) 1812
Operating Supply Voltage 8V
Max Current Rating 100A
Power Dissipation 1.2W
Max Voltage Rating (DC) 8V
Current - Max 100A
Hold Current 2A
Current - Hold (Ih) (Max) 2A
Max Supply Voltage (DC) 8V
Voltage - Max 8V
Time to Trip 2s
Resistance - Initial (Ri) (Min) 20mOhms
Resistance - Post Trip (R1) (Max) 60mOhms
Current - Trip (It) 3.5A
Trip Current 3.5A
Dimensions
Height 900μm
Length 4.73mm
Width 3.41mm
Thickness (Max) 0.035 0.90mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
