PTS12066V075
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric), Concave
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 6V 750MA 1206
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.16192
≥100 USD $0.154
≥500 USD $0.137808
≥1000 USD $0.128216
≥3000 USD $0.114013
Inventory: 5578
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric), Concave
Weight 453.59237mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2011
Series PolyTron?, PTS1206
Size / Dimension 0.128Lx0.065W 3.25mmx1.65mm
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
Termination SMD/SMT
Type Polymeric
Resistance 290mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated DC 6V
Case Code (Metric) 3216
Approval Agency cURus, TUV
Case Code (Imperial) 1206
Operating Supply Voltage 6V
Max Current Rating 100A
Power Dissipation 600mW
Max Voltage Rating (DC) 6V
Current - Max 100A
Hold Current 750mA
Current - Hold (Ih) (Max) 750mA
Max Supply Voltage (DC) 6V
Voltage - Max 6V
Time to Trip 200ms
Resistance - Initial (Ri) (Min) 100mOhms
Resistance - Post Trip (R1) (Max) 290mOhms
Current - Trip (It) 1.5A
Trip Current 1.5A
Dimensions
Height 850μm
Length 3.5mm
Width 1.8mm
Thickness (Max) 0.033 0.85mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
