PTR060V0375-TR
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC Resettable Fuse 40A 60VDC T/R
PDF
/
Inventory: 5343
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 28.4mm
Height Seated (Max) 1.319 33.50mm
Height 33.5mm
Technical
Trip Current 7.5A
Current - Trip (It) 7.5A
Resistance - Post Trip (R1) (Max) 80mOhms
Resistance - Initial (Ri) (Min) 30mOhms
Time to Trip 24s
Voltage - Max 60V
Current - Hold (Ih) (Max) 3.75A
Hold Current 3.75A
Current - Max 40A
Max Voltage Rating (DC) 60V
Power Dissipation 3.2W
Max Current Rating 40A
Lead Spacing 0.394 10.00mm
Operating Supply Voltage 60V
Lead Pitch 10mm
Approval Agency cURus, TUV
Voltage - Rated DC 60V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 50mOhm
Type Polymeric
Termination Radial
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.118Dia x 0.118 T 28.40mmx3.00mm
Series PolyTron?, PTR060V
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 453.59237mg
Package / Case Radial, Disc
Mounting Type Through Hole
Supply Chain
Factory Lead Time 14 Weeks
