PTR060V0185-BK
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC Resettable Fuse 40A 60VDC Poly Bag
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.55088
≥100 USD $0.53416
≥500 USD $0.449152
≥1000 USD $0.372856
≥3000 USD $0.338976
Inventory: 558
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 17.8mm
Height Seated (Max) 0.902 22.90mm
Height 22.9mm
Technical
Trip Current 3.7A
Current - Trip (It) 3.7A
Resistance - Post Trip (R1) (Max) 190mOhms
Resistance - Initial (Ri) (Min) 80mOhms
Time to Trip 12.6s
Voltage - Max 60V
Current - Hold (Ih) (Max) 1.85A
Hold Current 1.85A
Current - Max 40A
Max Voltage Rating (DC) 60V
Power Dissipation 2.1W
Max Current Rating 40A
Lead Diameter 800 μm
Lead Spacing 0.197 5.00mm
Lead Pitch 5mm
Approval Agency cURus, TUV
Terminal Pitch 5mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 120mOhm
Type Polymeric
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.701Dia x 0.118 T 17.80mmx3.00mm
Series PolyTron?, PTR060V
Published 2011
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Weight 453.59237mg
Package / Case Radial, Disc
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
