PTR030V0185-BK1
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 30V 1.85A RADIAL
PDF
/
Inventory: 6113
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Lead Pitch 5mm
Lead Spacing 0.197 5.00mm
Max Current Rating 40A
Power Dissipation 1W
Max Voltage Rating (DC) 30V
Current - Max 40A
Hold Current 1.85A
Current - Hold (Ih) (Max) 1.85A
Voltage - Max 30V
Time to Trip 8.7s
Resistance - Initial (Ri) (Min) 30mOhms
Resistance - Post Trip (R1) (Max) 90mOhms
Current - Trip (It) 3.7A
Trip Current 3.7A
Approval Agency cURus, TUV
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 60mOhm
Type Polymeric
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.402Lx0.118W 10.20mmx3.00mm
Series PolyTron?, PTR030V
Published 2011
Packaging Bulk
Operating Temperature -40°C~85°C
Dimensions
Height 15.7mm
Height Seated (Max) 0.618 15.70mm
Length 10.2mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Physical
Weight 453.59237mg
Package / Case Radial, Disc
Mounting Type Through Hole
Supply Chain
Factory Lead Time 14 Weeks
