PTR016V0185-BK1
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC Resettable Fuse 40A 16VDC Poly Bag
PDF
/
Inventory: 6233
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Disc
Weight 453.59237mg
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2011
Series PolyTron?, PTR016V
Size / Dimension 0.402Lx0.122W 10.20mmx3.10mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Type Polymeric
Resistance 51mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Approval Agency TUV
Lead Pitch 5mm
Lead Spacing 0.197 5.00mm
Max Current Rating 40A
Power Dissipation 1W
Max Voltage Rating (DC) 16V
Current - Max 40A
Hold Current 1.85A
Current - Hold (Ih) (Max) 1.85A
Voltage - Max 16V
Time to Trip 10s
Resistance - Initial (Ri) (Min) 30mOhms
Resistance - Post Trip (R1) (Max) 90mOhms
Current - Trip (It) 3.7A
Trip Current 3.7A
Dimensions
Height 15.7mm
Height Seated (Max) 0.618 15.70mm
Length 10.2mm
Width 3.1mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
